Sumiko Palo Santos Presentation

ΠΡΟΔΙΑΓΡΑΦΕΣ:

• Cartridge Type: Moving Coil
• Suspension: Synthetic Rubber
• Frequency Response: 10Hz-40Khz +/- 1.5dB
• Output Voltage/Channel: 0.5mV (3.54 cm/sec.,1kHz)
• Channel Separation: >30dB @ 1kHz
• Channel Balance: <0.5dB @ 1kHz
• Optimum Tracking Force: 2.0 grams
• Tracking Force Range: 1.8 - 2.2 grams
• Dynamic Compliance: 8 x 10-6 cm/dyne
• Internal Impedance: 12 ohms
• Load Impedance: 100-1k ohms
• Capacitance Range: 100 - 300 pf
• Cantilever: Long grain Boron
• Stylus: Line Contact, ultra low-mass, solid diamond 75µm x 5µm
• Output Terminals: Unique gold plated tapered brass pins
• Cartridge Weight: 8.3 grams
• Mounting System: Standard 0.5” hole spacing, threaded M2.5
