Ortofon Concorde digitrack

Προδιαγραφές

• Output voltage at 1000Hz, 5cm/sec: 8 mV
• Channel balance at 1kHz: 1,5 dB
• Channel separation at 1kHz: 22 dB
• Channel separation at 15 kHz: 15 dB
• Frequency range at -3dB: 20-20.000 Hz
• Frequency response: 20-18.000 Hz -3dB/-2 dB
• Tracking ability at 315 Hz at recommmende tracking force: 90 μm
• Compliance, dynamic lateral: 12 μm/m N
• Stylus type: Spherical
• Tracking force range: 2,0-4,0 g (20-40 mN)
• Tracking force recommended: 3,0 g (30 mN)
• Cartridge weight: 18,5 g
• Replacement stylus unit: Digitrak
