ATLAS Hyper Achromatic BiWire speaker Z 4:4 7m
Brand
ATLAS
Καλώδια ηχείων κατάλληλα για διπλοκαλωδίωση / διπλοενίσχυση
Calculating...
Καλώδια ηχείων κατάλληλα για διπλοκαλωδίωση / διπλοενίσχυση
A sophisticated bi-wire cable engineered to offer a high level of transparency and wide dynamic range.
The cable employs conductors comprising 72 0.25mm² high-purity OFC (Oxygen Free Copper) strands encapsulated within a carefully selected high-efficiency PTFE (Teflon™) dielectric coating. The resultant conductor is embedded within an anti-vibration filler and finished in the Hyper gloss black sleeve.
Our latest-generation Achromatic Z-plug is a proprietary low-mass, self-cleaning, precision-crimped (cold-weld) speaker connector fitted as standard. These cables are also available terminated with our cold-weld high quality OFC spades or our Transpose Modular Termination System. Transpose options include Z-plugs, expanding 4mm plugs or OFC spades in gold or silver.
Technology & Specifications
| Construction | Concentric multicore LF/MF, Solid core HF (1.2mm) |
| Material | 6n OFC |
| Dielectric | PTFE (Teflon™) |
| Screen | none |
| Capacitance | 163.98 pF/m |
| Inductance | 0.2303 µH/m |
| Resistance | 0.0060 Ohms/m |
| VOP | 0.69 |
| Outside Diameter | 8.5mm |
